| System installation – Configuration via the ABL Configuration Software

NOTE

Adaptation of further configuration options

If necessary, you can now adjust other parameters for the charging station such as Max. set charging current.

6 Now press the Group configuration button to

switch to that tab and enter the address of the charg-

ing station.

7 Click the Scan button on the right-hand side.

8 To change the address of the charging station, enter

the current address value in the left-hand field (in this

example: 3).

9 Now enter the new destination address for the charg-

ing station in the right-hand field (in this example:6).

10 Now click the Address manually button.

y The new address value is now activated.

11 Set the RCD of the addressed charging station to po-

sition 0.

12 Repeat steps 2 to 11 for all other charging stations in

the group, leaving all already addressed charging sta-

tions switched off.

13 After addressing all charging stations, set the RCDs

of all charging stations to positionI.

After completing the configuration, you can exit the ABL Configuration Software and disconnect the data cabling

with the computer via the CONFCAB cable.
