LVD SCSIDE Bridge Manual
4. ARS-2120
l CN1 --- 68-pin female SCSI connector.
l CN2 --- 40-pin female IDE connector (Slave).
l CN3 --- 40-pin female IDE connector (Master).
l CN4 --- 4-pin power connector.
l SW1 --- Refer to Figure 3-20 on page 35.
l SW2 --- Refer to Figure 3-21 on page 35.
Figure 2-4
SW1 CN4 SW2 CN2
CN1
CN3
To Next Page
