15
LVD SCSIDE Bridge Manual
5. ARS-2000LFS
l CN1 --- 68-pin female SCSI connector.
l CN2 --- 40-pin female IDE connector.
l CN3 --- 4-pin power connector, for supplying power to HDD.
l CN4 --- 4-pin power connector, for supplying power to the bridge.
l JP1 --- Refer to Figure 3-22 on page 36.
l SW1 --- Refer to Figure 3-23 on page 36
Figure 2-5
CN3 SW1
CN4
JP1
CN1
CN2
