72~81: Each waveform number of ten waveforms after U2 waveform is triggered
82~91: Each waveform number of ten waveforms after U3 waveform is triggered
92~101: Each waveform number of ten waveforms after I1 waveform is triggered
102~111: Each waveform number of ten waveforms after I2 waveform is
triggered
112~121: Each waveform number of ten waveforms after I3 waveform is
triggered
Note: Unless user retrieves all data from 8E00H to 8E43H in one time, Waveform
Group Number for Retrieving (8E01H) will automatically add 1, or Waveform
Group Number for Retrieving (8E01H) will keep present value if only retrieving
partial data.
8E00H
Waveform Group
Number for Retrieving
1~100
Note: When the value is smaller than or equal
to newest waveform record group number, this
value is valid.
8E01H
Waveform Group
Number
Waveform number
0~121
8E02H
Waveform record
window status
0x0BH: window data is valid.
0xFF: window data is invalid.
0xAA: waveform record memory is clearing(data
is invalid)
8E03H
Newest Waveform
Group Number
1~100
0~no record
8E04H-
8E43H
------
Waveform record data
retrieving window
-32768~ 32767
5. Relationship between voltage or current waveform value and real value
The relationship between voltage waveform value and real value:
Real Value (Unit: V) = Waveform Value / 37.59105
The relationship between current waveform value and real value:
