241
relationship listed below to count primary value, the value of CT2 should not be
333, but 1.
3)When you select 100mv/50Hz,or 120mv/60Hz Rope-CT,the value of CT2 is
100,and using relationship listed below to count primary value,the value of CT2
should not be 100,but 1;
4)When you select 80/100/200 mA CT,the value of CT2 is 80, 100 or 200, and
using relationship listed below to count primary value,the value of CT2 should
not be 80, 100 or 200, but 1.
Table 6-14
Parameters Relationship Unit Format code
System parameters
Numerical value equals to
communication value
No unit F1
Run time T=Rx/100 Hour F2
Clock
Numerical value equals to
communication value
Unit of time F3
Energy(primary) Ep=Rx/10 kWh F4
Reactive energy(primary) Eq=Rx/10 kvarh F5
Apparent energy(primary) Es=Rx/10 kVA F6
Energy(secondary) Ep=Rx/1000 kWh F7
Reactive energy (secondary) Eq=Rx/1000 kvarh F8
Apparent energy (secondary) Es=Rx/1000 kVA F9
Frequency F=Rx/100 Hz F10
Voltage U=Rx X(PT1/PT2)/10 V F11
Current, current demand I=Rx X(CT1/CT2)/1000 A F12
Power, demand P=Rx X(PT1/PT2)X(CT1/CT2) W F13
Reactive power, demand Q=Rx X(PT1/PT2)X(CT1/CT2) var F14
Apparent power, demand S=Rx X(PT1/PT2)X(CT1/CT2) VA F15
Power factor PF=Rx/1000 No unit F16
Unbalance factor Unbl=(Rx/1000)X100% No unit F17
THD THD=(Rx/10000) X 100% No unit F18
Harmonics HDn=(Rx/10000) X 100% No unit F19
