Note:
1) Please refer to Chapter 3 and Chapter 4 for more details about parameter
settings.
2) When 1038H is 2, second communicaton is set to MESH, you should
set 9600bps and NON1 for the second communication. When 1038H is 1,
second communication protocol is set to BACnet protocol, while second
communication should select BACnet module. When 1038H is 0, second
communication protocol is set to other protocols, while second communication
should select second RS-485 module, PROFIBUS module or Ethernet module.
If selected protocol doesn’t match attached module, communication can not
process. If you use Ethernet or PROFIBUS module, you should set 38400 bps and
NON1 for the second communication.When Ethernet or Profibus module will
connect nomarlly, user cann't change the protocol,baud and parity.
6.3.3 Date and Time Table
Function code: 03H for reading, 10H for presetting.
Table 6-17
Address Parameter Format code Range Data type Property
103FH week F3 0~6 word R/W
1040H Year F3 2000-2099 word R/W
1041H Month F3 1~12 word R/W
1042H Day F3 1~31 word R/W
1043H Hour F3 0~23 word R/W
1044H minute F3 0~59 word R/W
1045H second F3 0~59 word R/W
6.3.4 Over/Under Limit Alarming Setting
This setting consists of global alarm settings and single channel alarm settings.
Global alarm settings contain settings of all global variables. There are 16
groups of records with the same format. Function code: 03H for reading, 10H
for writing. Please refer to Chapter 4 for more details.
