248
Global alarming settings
Table 6-18
Address Parameter Range Data type Property
1046H Global alarming enable 0:disable;1:enable word R/W
1047H Alarming ash enable 0:disable;1:enable word R/W
1048H
Alarming channel enable
setting
0~65535
Bit0:channel 1
1:enable; 0:disable
Bit1: channel 2
……
Bit15: channel 16
word R/W
1049H
Logic “And ” between alarming
setting
0~255
Bit0: rst logic switch
1:enable;0:disable
Bit1: second logic switch
……
Bit7: eighth logic switch
word R/W
104AH Alarming output to DO1 setting
0~65535
Bit0: channel 1 output
1:enable;0:disable
Bit1: channel 2 output
……
Bit15: channel 16 output
word R/W
104BH Alarming output to DO2 setting
0~65535
The same as previous
word R/W
104CH Alarming output to DO3 setting
0~65535
The same as previous
word R/W
104DH Alarming output to DO4 setting
0~65535
The same as previous
word R/W
Single channel alarming settings
Table 6-19
Address Parameter
Format
code
Range
Data
type
Property
104EH First group: parameter code F1 0~79 word R/W
