3-28 Machine Maintenance Procedures
IO Board FPC Installation 0
1. Connect FPC (A) to mainboard connector (C). (Figure 3-37)
2. Connect FPC (A) to IO board connector (D).
3. Install tape (B) on FPC and secure to support plate.
4. Install battery. (non-3G SKU)
5. Install 3G module. (3G SKU)
