Acer A100 User Manual

3-44 Machine Maintenance Procedures
Home Key Board Removal 0
Prerequisite:
Mainboard Removal
1. Locate home key board (A). (Figure 3-61)
Figure 3-61. Home Key Board Overview
2. Remove home key board (A) from bezel.
3. Disconnect home key FFC (B) from board connector (C). (Figure 3-62)
Figure 3-62. Home Key FFC and Board Connector
A
B
C

Acer A100 Specifications

General

Display	7-inch TFT LCD, 1024x600 resolution
RAM	1 GB
Internal Storage	8GB or 16GB
Rear Camera	5 MP
Front Camera	2 MP
Dimensions	195 x 117 x 13.1 mm
Weight	410 g
Connectivity	Wi-Fi 802.11 b/g/n, Bluetooth 2.1, microUSB 2.0
Processor	NVIDIA Tegra 2 dual-core 1GHz
Operating System	Android 3.2 (Honeycomb), upgradable to 4.0 (Ice Cream Sandwich)
Battery	1530 mAh
