Acer A100 - Led 7.1

1-22 Hardware Specifications and Configurations
BD Drive (N/A)
LED 7.1”
Items Specifications
Vendor & Model
name
Performance
Specification
Transfer rate
(KB/sec)
Buffer Memory
Interface
Applicable disc
format
Loading mechanism
Power Requirement
Input Voltage
Item Specification
Vendor/Model name CMI/AT070TNA2
Screen Diagonal (mm) 255.52 mm
Active Area (mm) 222.72 mm x 125.28 mm
Display resolution (pixels) 1024 x 3(RGB) x 600
Pixel Pitch (mm) 0.2175mm × 0.2088 mm
Typical White Luminance
(cd/m
2
) also called Brightness
200 cd/m
2
Contrast Ratio 400 min / 500 type
Response Time (Optical Rise
Time/Fall Time) msec
8 ms / 12 ms
Typical Power Consumption
(watt)
2.17 W
Weight (without inverter) 190g max
Physical Size (mm) 235.5 mm x 143.5 mm x 5.2mm max
Electrical Interface 1 channel LVDS
Viewing Angle (degree)
Horizontal (Right) CR = 10
(Left)
Vertical (Upper) CR = 10
(Lower)
70 (Right) / 70 (Left) / 60 (Upper) / 60 (Lower) min.
