Machine Maintenance Procedures 3-37
4. Disconnect touch screen FPC (E) from mainboard connector (F). (Figure 3-50)
Figure 3-50. Touch Screen FPC and Mainboard Connector
5. Remove screws (G) from bezel. (Figure 3-51 through Figure 3-53)
Figure 3-51. Mainboard Screws (1 of 3)
E
F
G
G
