Acer AOD270 - LCD Bezel Removal

3-30 Machine Maintenance Procedures
LCD Bezel Removal 0
Prerequisite:
LCD (Liquid Crystal Display) Module Removal
1. Remove two (2) rubber screw seals (A) from the LCD module (Figure 3-29).
Figure 3-29. LCD Bezel Rubber
2. Remove two (2) screws (B) from the LCD module (Figure 3-30).
Figure 3-30. LCD Bezel Screws
A
A
B
B
