3-32 Machine Maintenance Procedures
LCD Bezel Installation 0
1. Place LCD bezel on the LCD module. Refer to Figure 3-32.
2. Press along the edges of the LCD bezel to secure the latches on the LCD module.
3. Install and secure two (2) screws (B) to the LCD bezel. Refer to Figure 3-30.
4. Install and secure two (2) rubber screw seals (A) to the LCD bezel (Figure 3-29).
5. Install the LCD module.
ID Size Quantity Screw Type
B M2.0*4.0 2
