Acer AOD270 - Lcd 10.1

Hardware Specifications and Configurations 1-29
LCD 10.1”
Item Specification
Vendor & Model name AUO
B101AW06 V0 LF
B101AW06 V1 LF
CMO
N101L6-L0D
CMI
N101L6-L0D
Screen Diagonal (mm) 255
Active Area (mm) 222.72 (H) × 125.28 (V)
Display resolution (pixels) 1024 × 600
Pixel Pitch (mm) 0.2175 (H) × 0.2088 (V)
Typical White Luminance (cd/m
2
)
also called Brightness
200 typ. (5 points average)
170 min. (5 points average)
Contrast Ratio 400 typ 400 min / 500 typ
Response Time (Optical Rise
Time/Fall Time) msec
16 typ / 25 max 7 typ / 12 max
Typical Power Consumption
(watt)
2.6 max. (Include Logic
and Blu power)
1.54 typ / 1.71 max
Weight (without inverter) 170 max
Physical Size (mm) 245.5 (H) × 147 (V) × 3.6 (D)
Electrical Interface 1 channel LVDS
Viewing Angle (degree)
Horizontal (Right)
CR = 10 (Left)
Vertical (Upper)
CR = 10 (Lower)
40 min / 45 typ
40 min / 45 typ
10 min / 15 typ
30 min / 35 typ
40 min / 45 typ
40 min / 45 typ
15 min / 20 typ
40 min / 45 typ
