Acer AOD270 - LCD Panel Removal

3-36 Machine Maintenance Procedures
LCD Panel Removal 0
Prerequisite:
LCD Bezel Removal
1. Find the camera module (C) on the LCD module. Refer to Figure 3-33.
2. Disconnect the camera cable (A) from the connector (B) (Figure 3-36).
Figure 3-36. Camera Disconnect
3. Remove the four (4) screws (D) (Figure 3-37).
Figure 3-37. LCD Panel Screws
A
B
D
D
