3-16 Machine Maintenance Procedures
Hard Disk Drive Installation 0
1. Connect the hard drive FPC (D) to the hard drive connector (E). Refer to Figure 3-13.
2. Install the hard drive into the hard drive compartment. Refer to Figure 3-12.
3. Connect the hard drive cable (B) to the mainboard connector (C). Refer to
Figure 3-11.
4. Install the base cover.
