Hardware Specifications and Configurations 1-17
Figure 1-6. Base View
Table 1-6. Base View
# Icon Item Description
1 Ventilation slots and
cooling fan
Enable the computer to stay cool, even after
prolonged use.
Note: Do not cover or obstruct the opening of
the fan.
2 Battery release latch Releases the battery for removal.
3 Battery bay Houses the computer's battery pack.
4 Battery lock Locks the battery in position.
5 Speaker Emits audio from your computer.
