Acer e-mill 3VS - Page 24

- 23 -
E-MILL 3VK MACHINE SPECIFICATIONS:
Range
Table Travel (X-axis)
50” Table: 28”/
711mm
Saddle Travel (Y-axis)
16 in. (406mm)
Quill Travel
5 in. (127mm)
Knee Travel (Z-axis
manual)
16 in. (406mm)
Ram Travel
24 in. (610mm)
Throat Distance (min.)
4
1
/
4
in. (171mm)
Throat Distance (max.)
28
1
/
4
in. (476mm)
Table to Spindle Nose
Gage line (min.)
1 in. (25.4mm)
Max. Weight of Workpiece
850 lbs. (386 kgs.)
Table
Overall Sizes
10 x 50 in. (254 x
1270mm)
T-Slots
3 on 2
1
/
2
in. (64mm)
centers
T-Slot Size
5
/
8
in. (16mm)
Height above floor (max.)
48 5/8 in. (1235mm)
Milling
Feed Rate (Power
Optional)
Please see Chart
Space and Weight
Floor Area
7 x 10 ft. (2.1 x
3.1m)
Height
96 in. (2438mm)
Net Weight
3300 lbs. (1500kgs)
Shipping Weight
3498 lbs. (1590kgs)
Power
Electrical Supply – 60/50
Hz.
3 phase
220/230/380/415/
440/460/575V
Color
Standard
Machine Gray/ACER
White with Burgundy
Stripes
