56 Chapter 3
Removing the Optical Drive Module
1. See “Removing the Battery Pack” on page 46.
2. Remove the Memory cover. See “Removing the Lower Covers” on page 49.
3. Remove the screw securing the ODD module.
4. Using a screw driver, push the ODD module through the chassis and pull to remove it from the main unit.
Step Size Quantity Screw Type
ODD Module M2.5*5(NL) 1
