88 Chapter 3
LCD Module Disassembly Process
LCD Module Disassembly Flowchart
Screw List
Step Screw Quantity Color Part No.
LCD Bezel M2.5*5 (NL) 4 Black MA000007YG0
Inverter Board M2.5*5 (NL) 1 Black MA000007YG0
Camera Module M2*3 (NL) 2 Black MA0000060G0
LCD Panel M2.5*5 (NL) 2 Black MA000007YG0
LCD Brackets M2*3 (NL) 8 Black MA0000060G0
