Chapter 3 71
9. The Upper Cover can now be removed from the lower base.
Removing the Finger Print Reader
1. See “Removing the Upper Cover” on page 67.
2. Remove the securing screw from the Finger Print Reader board, and ensure the FFC is free of the upper cover.
Step Size Quantity Screw Type
finger print reader M2.5*3 (NL) 1
To Next Page
