Acer Extensa 4630G - Removing the VGA Module

Chapter 3 87
Removing the VGA Module
1. Remove the mainboard. See “Removing the Mainboard” on page 79.
2. Remove the two securing screws from the VGA Module.
3. The VGA module lifts automatically from the mainboard. Remove the VGA Module as shown.
Step Size Quantity Screw Type
VGA Module M2*4-NI (NL) 2
