Acer Extensa 4630G - Removing the Upper Cover

Chapter 3 67
Removing the Upper Cover
1. See “Removing the Battery Pack” on page 46.
2. See “Removing the LCD Module” on page 65.
3. Turn the computer over. Remove the sixteen screws on the bottom panel.
Step Size Quantity Screw Type
Upper Cover M2.5x9 16
