Acer Extensa 4630G - Removing the LCD Bezel

Chapter 3 89
Removing the LCD Bezel
1. Remove the LCD module. See “Removing the LCD Module” on page 65.
2. Remove the two upper and two lower bezel screw caps. Remove the four securing screws from the LCD
module.
3. Lift up the bezel, topside first, and remove it from the LCD Module.
Step Size Quantity Screw Type
LCD Bezel M2.5*5 (NL) 4
