Chapter 3 65
Removing the LCD Module
1. Remove the Battery Pack. See “Removing the Battery Pack” on page 46.
2. Remove the Lower Covers. See “Removing the Lower Covers” on page 49.
3. Remove the WLAN Module. See “Removing the WLAN Module” on page 52.
4. Remove the Antenna. See “Removing the Antenna” on page 63.
5. Remove the two securing screws from the bottom of the chassis.
6. Turn the computer over. Disconnect the LCD cable from the top panel.
Step Size Quantity Screw Type
LCD Module M2.5*8(NL) 2
To Next Page
