62 Chapter 3
Removing the Launch Board
1. See “Removing the Battery Pack” on page 46.
2. See “Removing the Keyboard” on page 60.
3. Disconnect the Launch Board cable from the mainboard.
4. Remove the two securing screws from the Launch Board.
NOTE: The right hand securing screw is shared by the Power Board.
Step Size Quantity Screw Type
Power Board M2*3 2
To Next Page
