68 Chapter 3
4. Turn the computer over and disconnect the seven cables from the mainboard as shown.
Disconnect A as shown. If necessary, remove FFC G
before beginning.
Pull back the securing strip and disconnect B and C
as shown.
Remove the antenna cables from the housing and
pull back away from the upper cover.
Release the securing latches and disconnect E as
shown.
B
E
F
G
A
D
C
B
C
To Next Page
