Acer Extensa 4630G - Page 82

72 Chapter 3
3. Remove the board bracket from the Upper Cover.
IMPORTANT:Do not throw away the Bracket Pad. Remove and replace on new bracket.
4. Using your fingers, gently lift the Finger Print Reader board from the Upper Cover.
5. Pull the Finger Print Reader FFC through the touchpad bracket taking care not to fray the cable.
Bracket Pad
