80 Chapter 3
6. Remove the two securing screws from the Mainboard.
7. Lift the mainboard to expose the DC-IN jack and USB cable.
8. Remove the DC-IN jack and USB cable as shown.
Step Size Quantity Screw Type
Mainboard M2.5*9 (NL)
Green Call out
1
Mainboard M2.5*3 (NL)
Red Call out
1
