34 Chapter 3
4. Lift the optical drive off the mainboard and remove the bracket.
5. Remove the screws (C) securing the two brackets to the optical drive.
6. Remove the brackets.
Screw (Quantity) Color Torque Part No.
M2*2 (3) Silver 1.5  0.2 kgf-cm 86.9AJ32.2R0
