ACO 3233 - Description of Mode Set Screen

22
3. Description of mode set screen (2/2)
<Mode Set> 2/2
DC Out : Z
Meas time : 1ｓ
View : L10
baud rate : 9600
Samp Time : normal
● DC Out： Z ：Setting of output terminal
Select the ch outputted from the DC jack.
X Y Z
● Meas time： 1s ：Display of measuring time
Measuring time inputted with Meas time key appears.
Measuring time:
1s, 3s, 5s, 10s, 1m, 5m, 10m, 15m, 30m,
1h, 8h, 24h
● View： L10 ：Mode setting for hour rate vibration level
The mode set here is displayed on the normal screen.
L05, L10, L50, L90, L95
● baud rate： 9600 ：Setting of transmission rate
Set the transmission rate for the printer and personal
computer.
4800, 9600, 19200
● Samp Time： normal ：Setting of sampling time.
Normal ：Normal sampling time (100ms)
1s: Measure with sampling time of 1s.
(
Meas Mode
: This can be selected at
Auto 1
.)
･ These are changed at each time when setting is changed for operation.
･ The range, etc., can be changed on this screen.
