Communication Command
1. Interface
RS－232C
Transfer Speed ：4800、9600、19200bps
Data size ：8bit
Stop bit ：1bit
Parity check ：non
2. Format
ＣＭＤ ＤＡＴ ＣＲ ＬＦ
0Dh 0Ah
3. Command table（ＣＭＤ）
Capital letters pertain to PC command Small letters pertain to 3233 command
No Function Item
3233
↑
PC
PC
↑
3233
Function Outline
1 Time and date setting request
Ｔ
Setting Calendar
Time and date setting completed
ｔ
2 Configuration file transfer
Ｆ
Setting measurement condition
Configuration file transfer
ｆ
3 Start measurement
Ｓ
Start measurement command
Start measurement
ｓ
4 Stop measurement
Ｅ
Stop measurement command
Stop measurement
ｅ
5 Data acquisition completed
ｒ
Data acquisition completed
6 Data request
Ｄ
Data request command
Data transfer
DATA
Collect the completed data
7 Calibration
Ｃ
Setting the Cal mode on
Calibration mode command
ｃ
Only display
8 Back light
Ｌ
Lights up LED
ｌ
9 Independent range setting
Ｒ
ｒ
10 Filter setting
Ａ
ａ
11 Lp-value acquisition
Ｐ
Data transfer
DATA
Instantaneous value Data
Data： Variable size (ASCII)
Command：1Byte (ASCII)
