ACO 3233 - Page 31

30
4. Detail of Command
CMD
Function Item
Type of data
Outline of Functions
T
Time and date
setting request
ASCII(13) YYMMDDHHMMSS
t
Time and date
setting completed
Without data part
F
Transfer
Configuration file
ASCII(6)
S A B C D
*A, D ; common All CH
S
：CH Setting（１）
0；All CH １；X 2；Y 3；Z
A
：Meas Time Setting（１）
0；*** 1；1s
2；3s 3；5s
4；10s 5；1m
6；5m 7；10m
8；15m 9；30m
A；1h B；8h C；24h
B
：Range Setting（１）
2；110dB 4；90dB
C
：Filter Setting（１）
0；Lv 1；Lva
D
：Interval
0：Single 1：Repeat
f
Transfer
Configuration file
ASCII(＊) Reference to 6-2
S
Start measurement ASCII(1) Without data part
s
Start measurement 〃
E
Stop measurement ASCII(1) Without data part
e
Stop measurement 〃
r
Data acquisition Without data part
D
Data request ASCII(1) A
A: Setting CH(1) 0; All CH 1; X 2;Y 3; Z
Data transfer ASCII(1) Reference to 6-4
C
Data request ASCII(1) Without data part
c
Data transfer ASCII(1)
L
Data request ASCII(2) ０：Lights out １：Lights up
l
Data transfer ASCII(1)
R
Independent
range setting
ASCII(3) A B
A: CH Setting(1) 0;All CH 1; X 2; Y 3; Z
B: Range Setting(1) 0; 110 1; 90
r
Answer ASCII(1) Without data part
A
Filter setting ASCII(2) A B
A: CH Setting(1) 0;All CH 1; X 2; Y 3; Z
B: Filter Setting(1) 0; Lv 1; Lva
a
Answer ASCII(1) Without data part
P
Instantaneous
value
ASCII(1) A
A: CH Setting（1）0;All CH 1; X 2; Y 3; Z
Data transfer ASCII(5) Reference to 6-5
