ACO 3233 - Section 6 Output to Personal Computer

24
Section 6 Output to personal computer
This Vibration Level Meter has a function to output the measured data or data during
measurement to a personal computer.
●Operating system software：Microsoft Windows 98SE/2000/XP/Vista/7
* Windows 7 supports 32bit, 64bit.
1) Collection after measurement
Measured data can be collected via a personal computer with a separately sold dedicated
cable and software.
The collected data can be directly opened with spreadsheet software.
<Content of data>
2) Collection during measurement
When the Start･Stop key is inputted at the following setting, data is outputted for each
measuring time.
<menu> 1/2
＊＊＊＊ :＊＊
Interval : Off
I/O : Off
＊＊＊＊ :＊＊
<Content of output>
① 00/01/05_02:15:16_F_130dB+LF Measurement start date and time, dynamic
characteristic, range (+Line feed)
② 000h00m10s+LF Measuring time (+Line feed)
② Laeq:_130.0_ La05:_130.0+LF Data
② La10:_130.0+LF 〃
② La50:_130.0+LF 〃
② LMin:_130.0_ La90:_130.0+LF 〃
② LMax:_130.0 La95:_130.0+LF+LF 〃
③ 00/01/05_02:15:27_F_130dB+LF Next measurement start date and time,
dynamic characteristic, range (+Line feed)
One line of ① is outputted with the Start･Stop key input, and when the measuring time has
passed, the signal of ③ is outputted after the signal of ②. (The measurement start time is
transmitted to move to the next measurement.)
To end the measurement, input the Start･Stop key.
After the Start･Stop key is inputted, ② is transmitted.
In this case, for the measuring time (000h00m00s), in-process time is outputted.
For the data which cannot be calculated because of midstream ending, the “＊＊＊” mark is
outputted on the data part.
_: Space
LF: Line feed
Date Time
Direction
Range
Measurement time
Lceq Lmin Lmax La05 La10 La50 La90 La95
2003/02/03
15:55:45 X 110dB 000h00m01s 59.9 45.3 72.2 72.2 71.4 48.1 45.4 45.3
2003/02/03
15:55:46 X 110dB 000h00m01s 48 45.7 51.6 51.4 50.7 47.9 46 45.9
2003/02/03
15:55:47 X 110dB 000h00m01s 48.8 44.4 52.6 52.5 52 48.2 44.5 44.4
2003/02/03
15:55:48 X 110dB 000h00m01s 51.6 44 62.8 61.4 58.5 46.5 44.5 44
2003/02/03
15:55:49 X 110dB 000h00m01s 48.5 43.7 50.8 50.8 50.8 48.6 43.7 43.7
