<Appendix >
Appearance diagram of Vibration Level Meter TYPE3233
Extension cable connection diagram
※Please connect the extension cable to a cable (3m) between the main body of TYPE 3233.
Extension cable (5～100m)
Cable(3m)
TYPE 3233
Acceleration pickup
