MINIMUM CONDUCTOR SECTION
MAXIMUM LINE LENGHT
1,5 mm2
10 m
MAXIMUM CONDUCTOR SECTION
MAXIMUM LINE LEGHT
2,5 mm2
20 m
PLEASE NOTE
For longer lines, the conductor section must be increased in proportion.
, The cables (S11, S12 – S21, S22) connecting the timer and the X-ray signaling lamp for external use must be
two-pole type, of section 0,5mm2.
, The electric line characteristics must have the following characteristics (Chart C):
Chart C
MANUFACTURER’S RATING
PLATE
ELECTRICAL LINE
230 V ± 10% 115 V ± 10%
MAXIMUM VOLTAGE DROP 3 %
APPARENT LINE
RESISTANCE
0,5 Ω 0,2 Ω
ELECTRIC CONNECTIONS
WARNING
Prior to installing the radiographic system, it is advisable that all the electric connections are arranged.
TIMER
On the timer installation wall, according to the installation electric diagram, suitable runs for the following electric cables
must be provided:
⋅ timer electric cables;
⋅ cables for the connection between timer and tubehead;
⋅ cables for the connection between the timer and the X-ray signaling lamp for external use the system LIGHT
(OPTIONAL);
⋅ cables for the connection between the timer and the remote-control button the system ECB (OPTIONAL).
CAUTION
According to the relevant standard, the timer must be installed in a position that allows the operator to constantly
control the radiographic exposure.
TUBEHEAD
On the wall plate installation wall, a suitable run for the cable connecting timer and tubehead must be provided.
