Acteon x-mind dc - Changing the Configuration

INSTALLATION & MAINTENANCE MANUAL • X-MIND DC • (06) • 10/2018 • NXDCEN020F
Pag. 34 of 51
ON OFF
1
■
TUBEHEAD 1
2
■
TUBEHEAD
D
C
3
■
TUBEHEAD 2
4
■
TUBEHEAD DC
5
■
II° CONTROL BUTTON
6
■
LONG CONE 12’’ (31cm)
7
■
NOT AVAILABLE
8
■
NOT AVAILABLE
IF THE SHORT CONE IS USED 20cm = 8” (SSD)
ON OFF
1
■
TUBEHEAD 1
2
■
TUBEHEAD DC
3
■
TUBEHEAD 2
4
■
TUBEHEAD DC
5
■
II° CONTROL BUTTON
6
■
SHORT CONE 8’’ (20cm)
7
■
NOT AVAILABLE
8
■
NOT AVAILABLE
6.2. CHANGING THE CONFIGURATION
Possible modifications of the exposure values
►radiographic voltage (60kV/70kV)
►radiographic current (4mA/8mA)
►type of patient (ADULT/CHILD)
(refer to “User’s Manual”)
Possible modifications of the exposure values
►cone (8” /12”)
►type tubehead
► N° of control button
inside the timer, by changing the dip-switch position
THIS OPERATION MUST BE CARRIED OUT BY THE INSTALLER ONLY
DIP SWITCH ON OFF PARAMETER
1
INSTALLED
NOT INSTALLED
TUBEHEAD 1
2
dc
TUBEHEAD TYPE 1
3 INSTALLED NOT INSTALLED TUBEHEAD 2
4 dc TUBEHEAD TYPE 2
5 INSTALLED NOT INSTALLED II° CONTROL BUTTON
6 LONG 12’’ = 30cm SHORT 8’’ = 20cm CONE
7 NOT AVAILABLE
8 NOT AVAILABLE
INSTRUCTION
To change the number of the tubehead installed, move the dip-switch n° 1 or the dip-switch n° 3:
