INSTALLATION & MAINTENANCE MANUAL • X-MIND DC • (06) • 10/2018 • NXDCEN020F
Pag. 18 of 51
INSTALLATION SPECIFICATIONS
3.1. INSTALLATION SPECIFICATIONS
WARNING
Prior to installing the radiographic system, the Responsible Organization must as certain that:
the environment, the electric system and the power supply comply with the requirements needed,
otherwise he must provide the required adjustment.
ENVIRONMENT REQUIREMENTS
, The installation environment must be wide enough: check that the size and overall dimension of the
environment don’t present any obstacle while positioning the radiographic system.
, The environment must not be exposed to explosion hazards and must not be pressurized.
, While operating, the ambient temperature must range within +5°C and +40°C.
, The storage temperature must range within -15°C and +50°C.
, The relative humidity must range within 25% and 75%.
REQUIREMENTS OF THE SUPPORTING WALL
, The radiographic system supporting wall must be able to stand a 200 Kg tear at every fixing point.
PLEASE NOTE
It is mandatory to check the nature and consistency of the wall and, if required, ask the support of a
brickwork expert.
The walls of uncertain consistency must be provided with a buried counter plate or with a sandwich
type system.
REQUIREMENTS OF THE ELECTRIC SYSTEM
, The electric system must comply with the regulations in force.
, The electric system must be able to supply the power and voltage required in the manufacturer’s rating plate
of the radiographic system (Chart A).
Chart A
MANUFACTURER’S RATING PLATE
ELECTRIC SYSTEM
230 V ± 10% 115 V ± 10%
NOMINAL VOLTAGE 230 V 115 V
MINIMUM LINE VOLTAGE 207 V 103,5 V
MAXIMUM LINE VOLTAGE 253 V 126,5 V
ABSORBED POWER 1,2 kVA 1,1 kVA
MANUFACTURER’S RATING PLATE 230 V ± 10% 115 V ± 10%
