INSTALLATION & MAINTENANCE MANUAL • X-MIND DC • (06) • 10/2018 • NXDCEN020F
Pag. 30 of 51
ELECTRIC CONNECTION
5.1. ELECTRIC CONNECTION
CAUTION
Before proceeding to connections, the power supply must be cut off.
CAUTION
For electric safety, it is essential that the ground conductors are correctly connected.
WARNING
While performing the connection, always respect the polarity PHASE/ NEUTRAL.
WARNING
While stripping the cables, pay attention to the small copper wires that may fall on the printed circuit
and cause short circuits or malfunc
CONNECTION TO THE SUPPLY TERMINAL BOARD INSTRUCTION
1. Remove the terminal board cover 1 by unscrewing the fixing screw 2.
