ERROR MESSAGES
11.1. ERROR MESSAGES
The following chart gives a list of error messages that may appear while radiographic system is working.
The chart also includes the causes of the error messages and what to do to solve them.
ERROR
MESSAGES
CAUSE SOLUTION
E00 RX1 TUBEHEAD
IS NOT CONNECTED OR IS OUT OF ORDER
OUT OFF THE POWER SUPPLY
CHECK THE FUSES AND TUBE-HEAD
WIRING
E01 RX2 TUBEHEAD
IS NOT CONNECTED OR IS OUT OF ORDER
OUT OFF THE POWER SUPPLY
CHECK THE FUSES AND TUBE-HEAD
WIRING
E02
CORRUPTED EEPROM DATA
OUT OFF THE POWER SUPPLY
REPLACE TIMER BOARD
E03 EEPROM DATA NOT SAVED PROPERLY OUT OFF THE POWER SUPPLY
REPLACE TIMER BOARD
E07 LINE VOLTAGE VALUE NOT INCLUDED
WITHIN THE NOMINAL VALUE
CHECK MAIN LINE VOLTAGE
E08 THE X-ray KEY
ALWAYS SEEMS TO BE PRESSED
MAKE SURE IT IS NOT JAMMED OR
DEFECTIVE
E09 ANOMALY IN THE CONTROL PANEL CHECK FLAT CABLE WIRING OF KEYPAD
BOARD AND LED BOARD
E12
THE EXPOSURE
HAS BEEN PREMATURELY INTERRUPTED
KEEP THE X
-
ray KEY
PRESSED TILL THE END OF THE EXPOSURE
E20 ANOMALY IN THE TRIAC/RELAY OUT OFF THE POWER SUPPLY
REPLACE TIMER BOARD
E21 ANOMALY IN THE ELECTRONIC CIRCUIT OUT OFF THE POWER SUPPLY
REPLACE TIMER BOARD
E22 ANOMALY IN THE CONTROL CIRCUIT OUT OFF THE POWER SUPPLY
REPLACE TIMER BOARD
E23 INCORRECT DIP-SWITCH CONFIGURATION CHECK DIP-SWITCH CONFIGURATION
E24 THE CONTROL BUTTON DOES NOT CORRESPOND
TO THE SELECTED TUBEHEAD
CHECK DIP-SWITCH CONFIGURATION
E30
THE TUBEHEAD
DOES NOT WORK PROPERLY
CHECK TUBEHEAD WIRING AND TRY TO
MAKE A TUBE HEAD CALIBRATION
CHECK DIP-SWITCH CONFIGURATION
E32 THE TUBEHEAD
IS NOT IN THE CORRECT MODE
CHECK DIP-SWITCH CONFIGURATION
E33 THE TUBEHEAD
HAS NOT COMPLETED THE EXPOSURE
REPEAT THE EXPOSURE
CARRY OUT THE TUBEHEAD CALIBRATION
OTHERWISE, OUT OFF THE POWER SUPPLY
AND REPLACE IT
E40
PROBLEM IN THE FREQUENCY
OR REGULATION
CALL THE “ASSISTANCE SERVICE”
E41 THE TUBEHEAD
IS NOT CALIBRATED
CARRY OUT WITH THE CALIBRATION
OTHERWISE, OUT OFF THE POWER SUPPLY
AND REPLACE IT
E42 EEPROM DATA NOT SAVED PROPERLY CARRY OUT THE TUBEHEAD CALIBRATION
OTHERWISE, OUT OFF THE POWER SUPPLY
AND REPLACE IT
E43 CORRUPTED EEPROM DATA CARRY OUT THE TUBEHEAD CALIBRATION
OTHERWISE, OUT OFF THE POWER SUPPLY
AND REPLACE IT
