4.3. ASSEMBLING THE WALL PLATE
WARNING
When the timer is installed aside the wall plate, please consider what follows:
| the timer must be mounted on the left side of the wall plate;
|
the distance between timer and wall plate must be 2,5mm.
WARNING
When the timer is installed aside the wall plate, please consider what follows:
| the timer must be mounted on the left side of the wall plate;
|
the distance between timer and wall plate must be 2,5mm.
ASSEMBLY INSTRUCTION (refer to Fig. 6)
