INSTALLATION & MAINTENANCE MANUAL • X-MIND DC • (06) • 10/2018 • NXDCEN020F
Pag. 35 of 51
DIP
SWITCH
1 3
ON ON
OFF OFF
►if the tubehead is connected to the XRAY1 terminal board, put the dip-switch n° 1 in the ON position; otherwise in
OFF position;
►if the tubehead is connected to the XRAY2 terminal board, put the dip-switch n° 3 in the ON position; otherwise in
OFF position.
PLEASE NOTE
It is
possible
to connect to the
DC
timer
with
2
DC
tubehead
To change the amount of control buttons installed, move the dip-switch n° 5:
DIP
SWITCH
5
ON
OFF
►with second control button move the dip-switch n° 5 to the ON position.
PLEASE NOTE
After modification, each tubehead is controlled by the corresponding button.
To change the cone installed, move the dipswitch n° 6:
DIP
SWITCH
6
ON
OFF
►with short cone (8”=20cm (SSD)) move the dip-switch 6 to the OFF position;
►with long cone (12”=31cm (SSD)) move the dip-switch 6 to the ON position.
PLEASE NOTE
After modification, the set exposure times are automatically changed.
