Action technology A3 - Page 30

30
[Initial setting] 4 (Passing pulse width is 150ns or less)
[Setting range] 0 to 15
034.0
r
/
036.0
r
[Basic setting]
Division/ multiplication
(Numerator /
Denominator )
Set the parameters of position command pulse division/ multiplication.
When the number of upper command pulse and motor pulse per revolution is
different, calculate in terms of [(Numerator) / (Denominator )=(Number of
pulse per servo motor revolution) / (Number of host command pulse per
revolution)
[Setting example]
The number of pulse per motor revolution is 131072[pulse/rev]. Numerator can
be set 32768 by a quarter of 131072. Denominator can be set by a quarter of
the number of upper command per revolution. The corresponding parameter
setting of the number of upper command pulse per revolution is as follows.
Number of host
command per
revolution
Command division/
multiplication
(Numerator)
Command division/
multiplication
(Denominator)
131072
1000(Initial value)
1000(Initial value)
16384
32768
4096
10000
32768
2500
4096
32768
1024
4000
32768
1000
[Initial value] (Numerator / Denominator ) =1000/1000
[Setting range] (Numerator) 1 to 65535, (Denominator) 1 to 65535.
Setting range of Division/ multiplication ratio is from 0.001 to 1000.Normal
operation is not guaranteed while division/ multiplication ratio is beyond setting
range.
Yes
048.0
/
049.0
[Adjustment]
Analog command input
Filter parameter
(Numerator /
Denominator )
Low-pass filter parameter for smoothing analog speed command input.
It is valid when input filter selection (No.062.1) is set “1”,.
Parameter decrease→Smoothing effect becomes stronger, command
traceability reduces.
Parameter increase→command traceability increases,， susceptible to
interference
(Numerator / Denominator ) the value must be less than 1.
(Numerator / Denominator ) =1, filter invalid
[Initial setting] (Numerator / Denominator )= 16000/65535
[Setting range] 0～65535/1～65535
No
050.0
/
051.0
[Adjustment]
Analog command input
Gain
(Numerator /
Denominator )
Gain of analog speed command input.
When (Numerator) / (Denominator )=1 and ±10V analog command voltage is
input, the highest rotation speed of motor can be reached.
※As for the highest rotation speed of motor, refer to 「Basic specification」
According to different choice of symbol and polarity for analog command
voltage, the rotation direction of motor is different.
Decreasing this value has the effect of decreasing proportional gain of position
No
