[Initial value] 1000[ms]
[Setting range] 0 to 60000[ms]
387.
0
[Basic setting]
JOG operation: Target
speed
Set a target speed of the JOG operation.
[Initial value] 300[ r/mi n]
[Setting range] For 50W～100W：0～6300[ r/mi n]
For 200W～400W：0～5000[ r/mi n]
For 750W: 4500[ r/mi n]
For 1kW～2kW：0～3000[ r/mi n]
Note) Alarm occurs when it exceeds max. speed. Do not exceed the
max.speed.
No
388.0
[Basic setting]
Selection of Internal
speed command type
It is valid when control mode No.2.0 is set to “1=speed control mode” and
command mode selection No.3.0 is set to “3=Internal generation command” .
Select command type of internal speed command. No.390.0 and No.391.0 are
used to set acceleration/deceleration time of internal speed command.
No.392.0～399.0 are used to set the target speed.
0 = zero command input
1 = internal speed command(trapezoid speed command with 8 phases)
[Initial value] 0
[Setting range] 0 or 1
No
390.0
[Basic setting]
Internal speed command
Acceleration time
It is valid when control mode No.2.0 is set to “1=speed control mode” ,
command mode selection No.3.0 is set to “3=Internally generated
command” , and internal speed command type No.388.0 is set to “1=
trapezoidal speed command” . Set the acceleration time of internal speed
command input. Set the time of speed command from 0rpm to 1000rpm.
No.391.0 is used to set internal speed command deceleration time.
No.392.0～399.0 are used to set the target speed.
[Initial value] 1000 [ms]
[Setting range] 0 to 60000
No
391.0
[Basic setting]
Internal speed command
Deceleration time
It is valid when control mode No.2.0 is set to “1=speed control mode” ,
command mode selection No.3.0 is set to “3=Internal generation command” ,
and internal speed command type No.388.0 is set to “1= trapezoidal speed
command” . Set the deceleration time of internal speed command input. Set
the time of speed command from 1000rpm to 0rpm. No.390.0 is used to set
internal speed command acceleration time. No.392.0～399.0 are used to set
the target speed.
[Initial value] 1000 [ms]
[Setting range] 0 to 60000
No
392.0
393.0
394.0
395.0
396.0
397.0
[Basic setting]
Internal speed command
Target speed 1
Target speed 2
Target speed 3
Target speed 4
It is valid when control mode No.2.0 is set to “1=speed control mode” ,
command mode selection No.3.0 is set to “3=Internal generation command” ,
and internal speed command type No.388.0 is set to “1= trapezoidal speed
command” . Internal speed command acceleration/deceleration time is set in
No.390.0 and No.391.0. Set 8-phase target speed of internal speed command
input. The switch of target speed can be realized by following combination of
No
