Action technology A3 - Page 47

47
398.0
399.0
Target speed 5
Target speed 6
Target speed 7
Target speed 8
8pin, 9pin and 10pin in CN1.
Target
speed
I5(8pin in CN1)
I6(9pin in CN1)
I7 (10pin in CN1)
1
Open
Open
Open
2
Short circuited
Open
Open
3
Open
Short circuited
Open
4
Short circuited
Short circuited
Open
5
Open
Open
Short circuited
6
Short circuited
Open
Short circuited
7
Open
Short circuited
Short circuited
8
Short circuited
Short circuited
Short circuited
[Initial value]
Target speed 1: 500 [r/min]
Target speed 2: 1000 [r/min]
Target speed 3: 1500 [r/min]
Target speed 4: 2000 [r/min]
Target speed 5: 2500 [r/min]
Target speed 6: 3000 [r/min]
Target speed 7: 4000（200W～750W motor）[r/min]
3000（1KW～2KW motor）[r/min]
Target speed 8: 5000（200W～400W motor）[r/min]
4500（750W motor）[r/min]
3000（1KW～2KW motor）[r/min]
[Setting range] 0 to the highest speed of motor
642.
0
[Basic setting]
Internal speed command
- Operation mode
Set Operation mode for position control mode and internal generation
command.
0 = Point Table
1 = Communication operation
2 = Manual pulse input
[Initial value] 1 (Communication operation)
[Setting range] 0 to 2
No
643.
0
[Special setting]
Internal speed command
- Overflow detection
option
Enable/Disable Internal position command Overflow detection function.
0 = Disable
1 = Enable
To prevent the absolute position from disappearing when the target position
exceeds the absolute position range in Point table or communication
operation.
When “1 = Enable” is set and the target position (ABS position command) in
operation command exceeds absolute position, the alarm of internal position
command overflow will occur. When “0 = Disable” is set and the target position
exceeds absolute position, it can implement relative operation, not the
absolute operation. The relative operation is that the point table operation
Yes
