Display - Single Jet
Figure 4: Single Jet display
Legend:
Element 1: Parameter Jet channel 1
Element 2: Graphics respiratory tract pressure and etCO
2
Element 3: Alarm and notification field
Element 4: Measurements
Element 5: Help, menu and patient data keys
Element 6: Oxygen, Aux and humidification parameters
Element 7: Respiratory tract- and pause pressure limits
1
2
3
4
5
6
7
