Instructions for use MONSOON 5.6e
57/61 20/09/2010
TECHNICAL SPECIFICATION
Settings and Ranges
Jet frequency Jet 1: 12 – 1600 pulses/min (+ 2%)
Jet 2: 1 – 100 pulses/min(+ 2%)
Inspiratory time 15- 75 % (+ 2%)
Alarms:
- Pause pressure Jet 1: OFF - 100 mbar (+2%)
Jet 2: 1 - 100mbar (+2%)
- Airway pressure 1 - 100 mbar (+ 2%)
- Disconnection On - Off
Driving pressure 0.1 - 3.5 bar (+ 2%)
Oxygen concentration 21 - 100% (+ 3%)
Minute volume measurement 0 - 200 l/min (+ 10%)
Tidal volume measurement 0 – 10,000 ml (+ 10%)
Bypass Flow 0 - 70 l/min
Max. water flow 6 ml/min
Max. heater output 200 Watt
Dimensions
Main unit:
W x H x D 42 cm x 19 cm x 39 cm
Weight: Basic:approx. 13.5 kg
PLUS:approx. 14.0 kg
PLUS Double jet: approx. 15.8 kg
Control panel:
W x H x D 27 cm x 8 cm x 21 cm
Weight: approx. 1.5 kg
Connections / Ports
Air supply 4.0 to 6.5 bar
Oxygen supply 4.0 to 6.5 bar
Power supply 100 to 240 VAC 50/60 Hz
Average power consumption: 100 W
Ethernet port LAN connection / HL7
