ACUTRONIC MONSOON - Display - Double Jet

Instructions for use MONSOON 5.6e
20/09/2010
18/61
Display - Double Jet
Figure 5: Double Jet display
Legend:
Element 1: Parameter Jet channel 1
Element 2: Graphics respiratory tract pressure and etCO
2
Element 3: Alarm and notification field
Element 4: Measurements
Element 5: Help, menu and patient data keys
Element 6: Parameter Jet channel 2
Element 7: Oxygen parameter
Element 8: Respiratory tract- and pause pressure limits
8
1
2
3
4
5
6
7
