ACUTRONIC MONSOON - Rear View; Connections

Instructions for use MONSOON 5.6e
59/61 20/09/2010
Rear View / Connections
Figure 14: MONSOON - rear view
Legend:
Element 1: AIR input (NIST)
Element 2: O
2
input (NIST)
Element 3: Fan
Element 4: Nurse Call connection
Element 5: Drop counter connection
Element 6: Remote control connection
Element 7: LAN / HL7 port
Element 8: Mains switch
Element 9: Mains connector (100 – 240V)
Element 10: Earthing connector
Element 11: Nameplate
Element 12: O
2
bleed
Element 13: CO
2
bleed
Element 14: Bottle mount priming
3
1 2
4 5
6 7
8
9
10
12
13
11
14
