• push CENTRE to enter menu or to say OK;

o push RIGHT to go down into the submenu;

o push LEFT to go up from the submenu;

o push UP to scroll up the menu;

o push DOWN to scroll down the menu;

• fast RIGHT push: activates auxiliary window. This window displays the results of main

Application (screening) and additional Application;

• long LEFT push: activates keyboard to insert patient name and date of birth;

• long RIGHT push: Screening Mode: Selection of age interval for standard screening:

push RIGHT to switch between 'Ok' button, 'Cancel' button and the list of age intervals.

To move inside the list of age intervals, press CENTRE button. (NOTE: if the date of birth

has been already inserted via the long LEFT push, then the age interval is automatically

set);

• long UP push: changes positive and negative cylinder representation for the running

measurement;

Menu tree is described in the Menu paragraph.

During the examination some keys change their function:

• push LEFT to toggle ON/OFF the sound;

• push RIGHT to toggle ON/OFF the light;

After the measurement:

• push CENTRE to enter menu;

• push RIGHT to display the auxiliary window;

Active keyboard mode buttons:

• Cross button CENTRE: select the field (or letter) highlighted;

• Start button: Enter;

• Cross button, UP/DOWN/RIGHT/LEFT buttons: move between characters;

• Button A: exit;

• Button B: moves the cursor in different fields;

• Button C: backspace;

• Button D: resume;
